Connection status: ASMTXHCI:ASMTHUB3:USB 2.00 High-Speed
Interface: UFI High-Speed
Serial number: 0011-8840-0030
Boot version: 1.04, FW version: 1.10 (Mar 26 2017 14:24:34)
Insertion test... Done
VCCQ not properly connected
Init bus...
VCC: 3.3 V, VCCQ: 1.8 V
Bus: 1 bit (SDR 48MHz)
Access mode: sector mode
Power supply: dual-voltage (1.70-1.95V, 2.7-3.6V)
Card/BGA: BGA (Discrete embedded) - High density MMC
Manufacturer ID: 0x15 (Samsung)
Product name: RH64AB (0x524836344142), rev: 0x05, serial number: 0x1D189BA1
Manufacturing date: Feb 2019
CID: 15010052 48363441 42051D18 9BA126A8
CSD: D0270132 0F5903FF F6DBFFEF 8E40400C
EXT_CSD revision: 1.8 (MMC v5.1)
Partition info:
Boot1: 4096 KiB
Boot2: 4096 KiB
RPMB: 4096 KiB
User area: 58.24 GiB(62,537,072,640 bytes)
Cache size: 64 MiB
Hardware reset function: 1
Partition configuration: 0x38
No boot acknowledge is sent (default)
User area is enabled for boot
Partitioning support: 0x07
Device support partitioning feature
Device can have enhanced technological features
Device partitioning possible
Boot configuration protection: 0x00
Boot bus conditions: 0x00
Boot area write protection: 0x00
Power-on write protection: possible
Permanent write protection: possible
Lock status: not locked
ANDROID System Info:
platform: msm8953, cpu abi: arm64-v8a
manufacturer: OPPO
board: msm8953, name: PBBM00
brand: OPPO, model: PBBM00 (R11s)
build model list: CPH1829 (CPH1829)
build id: OPM1.171019.026, version: 8.1.0 Oreo (PBBM00EX_11_A.24)
build description: S88051AA1-user 8.1.0 OPM1.171019.026 eng.root.20190803.101558 release-keys
Internal storage: 52.81 GiB
crypto state: unencrypted
Custom moviNAND command is not supported for this device(MMC51).
Selected: [SAMSUNG] KMRH60014A-B614/64GB (BGA221)
i have done factory reset and frp then it stuck at 9008 mode need help
